ESX QXE5.2C Quantum Series 13 cm (5.25″) 2-Way Component Speakers

ESX QXE5.2C

With the QUANTUM QXE Series ESX offers a high-quality and visually appealing speaker series, which has several new highlights to offer. The novel composite cones made of polypropylene with carbon reinforcement are additionally reinforced in the component systems with very stable glass fiber dust caps. Result: high sound NEWtrality and low distortion. Extremely powerful magnet drivers ensure very high efficiency up to 90 dB/W/m. This in turn ensures a clean bass performance with a lot of dynamics. The 25 or 30 mm voice coils on all models, in combination with the powerful magnets, deliver a high load capacity, since the magnets ensure a good dissipation of the heat. The compact crossovers are separated for bass and treble and are easy to install. The whole thing is perfected by the 25 mm silk-dome-tweeters, which reproduce a very clear and brilliant sound without being obtrusive.

Specifications

• 13 cm (5.25″) 2-Way Component System
• Power Rating 90/180 Watts RMS/Max.
• Impedance 4 Ω
• Frequency Range 62 – 22000 Hz
• 25 mm Voice Coils
• 12,9 oz. (0,36 kg) Magnet Drivers
• 25 mm Silk Dome Neodymium Tweeters
• Separate Crossovers for Tweeter and Bass
• incl. –6/–3db attenuation for treble
• Protection Grilles
• Installation depth 54 mm
• Installation diameter 115 mm
