JL Audio 10W0v3-4 – 10″ W0v3 Series Car Subwoofer Driver

JL Audio 10W0v3-4 – 10″ (250 mm) Subwoofer Driver

W0v3 10-inch Subwoofer (300 W, 4 Ω)

The 10W0v3 is a rugged performer with excellent excursion capability and linearity and an overall performance envelope that puts it right at the top of its price class. It features a beefy 2 in. diameter voice coil and our Elevated Frame Cooling design for enhanced power handling and reliability.

The 10W0v3 is best used with amplifier power in the 75W – 300W range and is optimized to operate in a compact 0.65 cu. ft. (18.4 l) sealed enclosure, or a 1.125 cu. ft. (31.9 l) ported enclosure.

Specifications

• Continuous Power Handling (RMS): 300 W
• Recommended Amplifier Power (RMS): 75 – 300 W
• Nominal Impedance (Znom): 4 Ω
• Product dimensions: 267 x 267 x 124 mm
