Musway M6v3-24V Digital 6-Channel Amplifier With 8-Channel DSP 4ohm Dual 32bit 24Volt

Musway M6v3-24V Digital 6-Channel Amplifier

The popular M6v3 amp is now also available as a 24V version for trucks and buses. You would never guess that the small housing houses a full-blown Class D amplifier that powers six bridgeable outputs in pairs, each with 125 watts RMS per channel (into 2 ohms). A total of 750 watts RMS is therefore available. The compact dimensions are made possible by an elaborate 4-fold laminated circuit board, which also effectively suppresses EMC interference due to the favorable topology – a must for full-range Class D amplifiers.

The heart of the amplifier is the state-of-the-art DSP chip ADAU1452 from Analog Devices, which has been finely tuned by MUSWAY engineers and leaves nothing to be desired by audiophiles. The amplifier is connected via a space-saving cable harness with ISO plugs, individual plug+play cable sets are also available. Useful additional features include soft clipping to protect the electronics and speakers in 2-ohm operation and the newly developed high-level input with error protection system, which prevents any functions from being impaired or error messages from being written to the vehicle memory when connected to OEM factory radios.

Features:

• Intelligent high-level input with EPS (Error Protection System)
• Start-stop ready, automatic switch-on function
• Burr-Brown converter (PCM3168A) and Analog Devices DSP (ADAU1452)
• Dual 32bit, 330 MHz DSP technology, controllable via new V3 DSP software and V3 app
• Soft clipping (power attenuation) in 2 Ohm mode
• Signal-to-noise ratio ≥90dB, frequency response 15 Hz – 22 kHz (-3dB)
• Distortion factor ≤0,1% (1 kHz, 4Ohm, 90% power)
• Separately adjustable input sensitivity (channel 1-4, channel 5-6), clipping LED
• External Bluetooth® USB dongle BTS, BTS-HD & BTA2 for audio streaming & app control (optional)
• Digital remote control DRC1 with OLED display for controlling various DSP functions (optional)
• Quick Connect Terminal for connecting MUSWAY subwoofer systems
• Cable set with open ends (ISO cable set optionally available)

Technical Data

• 6 x 90/125 Watt RMS @ 4/2 Ohm or
• 3 x 250 Watt RMS 4 Ohm bridged
• 6 x high level input 4.8 – 20 V RMS
• 6 x low level input* (RCA) 2 – 6 V RMS
• 1 x AUX input/stereo (RCA) 2 – 6 V RMS
• 1 x input optical/stereo (PCM, 96 kHz / 24 bit)
• 6 x amplified speaker output (CH5/6 Quick Connect)
• 2 x preamplifier output (RCA) 4 V RMS
• Dimensions: 150 x 44 x 220 mm
